LiFePO4 AGV Battery 48V Lithium Battery Pack for Robots Logistics Handling AGV Customization Support
| Technical Specifications | |||
| Nominal voltage | 48V | Nominal capacity | 26Ah |
| Energy | 1248Wh | Internal resistance | 40mΩ |
| Series and parallel | 15S8P | Output terminal | SAS50A |
| Discharge current | 13.2A | Max.continuous discharge current | 60A |
| Charge current | 13.2A | Max. charge current | 52.8A |
BMS over-discharge protection current | 70A | Charging voltage | 54.75V |
Over-discharge protection voltage | 37.5V | Overcharge protection voltage | 32.4V |
Over-discharge recovery voltage | 45V | Overcharge recovery voltage | 54V |
| Discharge temperature | -20-60°C | Charging temperature | 0-45°C |
| Storage temperature | -5-45℃ | Communication | RS485 |
| Size | 530*155*128mm | Weight | 17KG |
| Shell material | SPCC | Protection level | IP42 |
| Cycle life | ≥2000 times | Self-discharge | ＜1% per month |
Product Features:
Customization Support: Personalized customization services are available to meet diverse needs.
Intelligent Control: Battery SOC, voltage, temperature, and other information are uploaded in real time and can be accessed by the device at any time.
Intelligent BMS: Overcharge/over-discharge/over-temperature/over-current/short circuit protection.
Low Power Consumption: Low power consumption design for long standby time.
Application scenarios:
Warehousing; logistics; Handling AGV .
