2.4V 40Ah lithium titanate battery 96Wh LTO battery

Product Parameter

Weight:1050g±15g

Nominal capacity:40Ah@1C₁A(40A)

Nominal voltage:2.4V

Nominal Energy:96Wh

Energy Density:91.4Wh/kg

Resistance:≤0.3mΩ(AC, 1000Hz)

Charging cut-off voltage:2.9V

Discharging cut-off voltage:15V

Standard charging current:1C₁A(40A)

Standard discharging current:1C₁A(40A)

Max. Constant Charging Current:6C₁A(240A)

Max. Constant Discharging Current:8C₁1A(320A)

Max. Charging Current:12C₁A(480A)

Max. Discharging Current:20C₁A(800A)

Packaging method

Carton dimensions (W×L×H) : 380×380×27mm

Gross weight: 28kg

Each battery pack is in a separate anti-static or protective sleeve

Cells between foam or cardboard partitions to prevent movement and short circuits

Inner boxes for batch production of 25 cells (varies by order)

The outer packaging carton is made of high-strength double-layer corrugated cardboard
