LiFePo4 Battery Cell 32140 3.2V 15Ah 15000mAh Lithium Rechargeable Battery Large Capacity EV

Product Introduction

The 32140 LiFePO₄ (Lithium Iron Phosphate) battery cell delivers a reliable 3.2V nominal voltage and high capacity of 15Ah (15000mAh), making it ideal for electric vehicles, solar energy storage systems, and industrial battery packs. Known for its excellent safety, long cycle life, and thermal stability, this cylindrical cell ensures high-performance output even in demanding conditions.

Key parameters

Model: 32140FS

Typical capacity: 15Ah

Minimum capacity: 14.8Ah

Nominal voltage :3.2V

Cathode material: LFP

Ac internal resistance: 1.0mΩ≤IR≤3mΩ

Cell weight: 290.0±10.0g

Energy density: 165Wh/kg - 396Wh/L

Operating voltage: 2.0-3.6V

Standard charging cut-off voltage: 3.6V

Discharge cut-off voltage: 2.0V

Maximum continuous discharge current: 2C

Maximum continuous charging current: 1C

Maximum pulse discharge current: 6C (10s)

Cycle: ≥2500 cycles

Charging temperature: 0-60℃

Discharge temperature: -20 to 60℃

Maximum charging cut-off voltage: 3.8V

The optimal charging temperature range :15~ 40℃

Usage scenarios

Energy storage

Electric vehicle

Material and style

Lithium iron phosphate battery（LiFePO4）

Cylindrical cell

Packing and shipping

Packaging method

Each battery pack is in a separate anti-static or protective sleeve

Cells between foam or cardboard partitions to prevent movement and short circuits

Inner boxes for batch production of 40 cells (varies by order)

The outer packaging carton is made of high-strength double-layer corrugated cardboard

All cartons are marked with product model, voltage, capacity and safety labels

Optional customization

OEM identification or barcode label

Bulk pallets or shrink packs are available upon request

When transported by land or air, there are 15 boxes on each layer of the cardboard, stacked ≤ 5 layers. When transported by sea, there are 16 boxes on each layer of the cardboard, stacked ≤ 7 layers.

Shipment: The cell shall be shipped in 25-30% state-of-charge (SOC) or in accordance with customers' requirement. The voltage range for cell shipment is 3260-3320mV ( The specific range of shipment voltage is subject to the label) .The remaining capacity of the cell after shipment and before charging depends on the storage time and conditions.

Tip: The cell that has been unused for more than 3 months is recommended to be used after recharge.

Shipping Details

Shipping Methods:

Sample orders: Express (DHL, UPS, FedEx, TNT)

Bulk orders: Air freight or sea freight

For packaging of large quantities of goods, shrink wrap and edge protection are used for palletization.

Export Documentation & Certifications:

UN38.3 certified for lithium battery transportation

MSDS, RoHS, and IEC/CE certifications available

Dangerous Goods Declaration (DGD) provided for international shipping compliance
