3,2 В 100 А·ч низкотемпературный аккумулятор LiFePo4 призматический элемент
Product parameters | |||
| Rated capacity | 100Ah | Nominal voltage | 3.2V |
| Charge Ending voltage | 3.65V | Discharge ending voltage | 2.5V (＞0℃), 2.0V (≤0℃) |
| Internal resistanc | ≤0.5mΩ (AC Impedance, 1000 Hz) | Weight | 2.10±0.1 kg |
| Standard charge current | 25±2℃, 0.5C | Standard discharge current | 25±2℃, 0.5C |
| Charge temperature range | -10℃～+55℃ | Discharge temperature range | -40～+60℃ |
| Storage temperature (Recommended) | -10～+35℃ | Storage temperature (Short-term allowance) | -30～+55℃ |
| Cycle Life | ≥4000 cycles 80% EOL | Nominal energy | 320Wh |
| Max. charge limited current at room temperature (Non-cyclic) | 150A (Continuous) / 300A (50%SOC, 10s) | Max. discharge limited current at room temperature (Non-cyclic) | 200A(Continuous) / 300A (50%SOC, 10s) |
